Overview
An e-mountain bike with almost infinite capacity, designed to overcome both vertical descents and technical climbs. And with all the specific technology for integrated electric all-mountain.
Tech Specs:
Frame: 150mm travel, SmartForm C2 Alloy, Cannondale Tuned Suspension, removable downtube battery, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
Fork: RockShox 35 Silver R, 150mm, Solo Air, 15x110mm stealth thru-axle, tapered steerer, 51mm offset
Rear Shock: RockShox Deluxe Select R, DebonAir
Headset: Integrated Sealed Bearing, Tapered
Stem: Cannondale 3, 3D Forged 6061 Alloy, 1-1/8″, 31.8, 7°
Handlebar: Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
Saddle: Cannondale Ergo XC
Seatpost: TranzX dropper, internal routing, 31.6, 100mm (S), 120mm (M), 130mm (L-XL)
Pedals: Not included
Grips: Fabric Funguy
Groupset:
Rear Derailleur: SRAM SX Eagle
Front Derailleur: N/A
Crank: FSA E-Bike, 165mm, SRAM Eagle, 34T Steel
Shifters: SRAM NX Eagle, 12-speed
Cassette: SRAM PG-1210, SX Eagle, 11-50, 12-speed
Chain: SRAM SX Eagle, 12-speed
Brakes: TRP Slate G4 4 Piston hydraulic disc, 200/200mm rotors
Brake Levers: TRP hydraulic disc
Wheelset:
Rims: WTB STX i25 TCS, 32h, tubeless ready
Spokes: Stainless steel, 14g
Front Hub: (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT400, 12x148mm thru-axle
Rear Hub: (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT400, 12x148mm thru-axle
Tires: Maxxis Rekon, 29 x 2.6″, 60TPI Exo
Electric Components:
Motor: Shimano EP8
Battery: Shimano BT-E8036, 630Wh
Remote: Shimano SC-EM800, Bluetooth enabled
Charger: Shimano Battery Charger 2A









Reviews
There are no reviews yet.
